Heavy Duty Rv Solar Mounting Brackets Solar Mount Joint Aluminum Alloy Connector

  • 1
  • 2

Delivery Time : 15-20 work days

Compatible Profile : Standard Solar Mount Rails, 41×21 Strut Channel

Size : Standard size/ Customized

Price : Discuss

Surface Treatment : Hot Dip Galvanized

MOQ : 500 pcs

Payment Terms : T/T, T/T

Type : Fixed Joint

Brand Name : Jiucan Metal

Place of Origin : Hebei,China

Material : Q235/Steel

Certification : ISO9001

Product name : Solar Mounting Bracket Joint

Load Capacity : 200kg – 600kg

Packaging Details : 50 Or 100PCS Are Packed In Steel Pallet , And Fasten With Steel Strips

Thickness : 5-6mm/ Customized

Supply Ability : 50 to 80+ tons/day

Application : Solar Racking, PV Panel Mount, Ground & Roof Solar System

Process Service : Cutting ,Punching

Tolerance : ±3%

Contact Now

Heavy Duty Solar Mount Joint Aluminum Alloy Connector

Introduction

This heavy duty aluminum alloy solar mount joint is a high-performance connecting component for modern photovoltaic mounting systems. Made of premium AL6005-T5 aluminum alloy with anodized surface treatment, it combines lightweight structure with exceptional strength and corrosion resistance. Ideal for high-standard solar projects, commercial PV stations and lightweight rooftop installations, it effectively reduces overall system weight while ensuring strong connecting performance. The joint firmly links solar mounting rails and support structures, providing stable support for PV panels under various weather conditions. Aluminum alloy material naturally resists rust and oxidation, requiring no regular maintenance and offering a service life of over 25 years. Precision extrusion and CNC machining ensure accurate dimensions and smooth assembly. Compatible with standard aluminum solar mounting systems, it supports fast modular installation. Certified by international standards, it is a high-end lightweight connecting solution for durable photovoltaic systems.

Features

The aluminum alloy solar mount joint features lightweight AL6005-T5 construction for high strength and low weight. Anodized surface treatment provides excellent anti-corrosion, anti-UV and anti-aging performance. Its lightweight design reduces roof load while maintaining reliable structural stability. Precision machining ensures accurate dimensions and tight, gap-free connection. The aluminum material is rust-proof and maintenance-free, suitable for long-term outdoor use. High weather resistance ensures stable performance in extreme temperatures and humid environments. Universal compatibility supports most aluminum solar mounting systems for flexible project design. Eco-friendly and recyclable, it meets green energy project requirements. With long service life and reliable connecting performance, it provides efficient high-end connection solutions for photovoltaic mounting systems.

Specification

Parameter Details
Product Name Solar Mounting Bracket Joint, PV Racking Connector, Solar Structure Joint
Material Q235B Steel, AL6005-T5 Aluminum Alloy
Surface Treatment Hot Dip Galvanized, Pre-Galvanized, Anodized
Type Fixed Joint, Adjustable Joint, Corner Joint
Compatible Profile Standard Solar Mount Rails, 41×21 / 41×41 Strut Channel
Hole Specification Round Hole φ11 / φ13.5; Slotted Adjustment Hole
Thickness 2.5mm, 3.0mm, 4.0mm, 5.0mm
Load Capacity 200kg – 600kg
Wind Load Up to 60m/s
Snow Load 1.2 – 2.0 kN/㎡
Working Temperature -40℃ ~ +120℃
Adjustable Angle Fixed / 0°–90° adjustable
Installation Bolt Fastening, Tool-Free Assembly
Application Solar Racking, PV Panel Mount, Ground & Roof Solar System
Service Life 20–30 years
Certification ISO9001, CE, TUV, SGS Test Report
MOQ 100pcs, Small Trial Order Acceptable
OEM / ODM Size, Hole, Thickness, Logo Customizable
Packing Carton + Pallet



Heavy Duty Rv Solar Mounting Brackets Solar Mount Joint Aluminum Alloy Connector


FAQ

Q: Do you provide free sample?
A: Yes, but please note the transportation charge will be paid on your side.

Q: What kind of materail you can offer?
A: We can offer you GALVANIZED STEEL, STAINLESS STEEL, ALUMINUM, CABLE TRAY.
Q: What kind of standard you are following?
A: We are producing following by GB/T19001-2008, ISO9001:2008, SGS, MA...
Q: Could you change the size for the customer?
A: Yes, depends on your special demands.
Q: How many days delivery the order?
A: Normally 20 days after deposit or L/C, depends your request.
